Big-eyed hooks 320 thick body
Hoop swivel hook
Fork swivel hook
snap hook 2
 |  |
| Product Name | Model | Inner diameter | Ring diameter | Total height | Opening Hook | inner diameter | Hook outer width | Hook thickness |
| Big-eyed hooks | 0.2T | 19 | 7 | 92 | 17 | 25 | 47 | 9.5 |
| 0.3T | 20 | 7.5 | 101 | 17 | 26 | 49 | 10.5 | |
| 0.5T | 28 | 9.5 | 118 | 18 | 29 | 57 | 12 |
| Product Name | Model | Inner diameter | Ring diameter | Total height | Opening Hook | inner diameter | Hook outer width | Hook thickness |
| 320 thick body | 0.5T | 16.5 | 8 | 89 | 15 | 21 | 52 | 12 |
| 0.75T | 19 | 9 | 101 | 23 | 24 | 60.5 | 10.5 | |
| 1T | 23 | 11 | 113 | 21 | 26 | 64 | 15 | |
| 1.5T | 28 | 12 | 128 | 20.5 | 29 | 73 | 17 | |
| 2T | 32 | 15 | 150 | 25 | 34 | 86 | 18 | |
| 3T | 38 | 18 | 182 | 31 | 39 | 106 | 24 |
| Product Name | Model | Inner diameter | ring Inner Height | Ring Dia | Total height | Opening Hook | inner diameter | Hook outer width | Hook thickness |
| Hoop swivel hook | 0.15T | 16 | 18 | 5 | 90 | 11 | 18 | 39 | 8 |
| 0.35T | 22 | 23 | 6 | 113 | 15 | 24 | 52 | 11 | |
| 0.65T | 27 | 29 | 8 | 138 | 20 | 27 | 59 | 12 | |
| 1T | 28 | 30 | 10 | 155 | 23 | 33 | 72 | 15 | |
| 1.5T | 36 | 36 | 12 | 188 | 30 | 37.5 | 81 | 17 |
| Product Name | Model | Inner Width | ring Inner Height | Pin diameter | Total height | Opening Hook | inner diameter | Hook outer width | Hook thickness |
| Fork swivel hook | 0.15T | 10.5 | 16.5 | 6 | 90 | 11 | 17.5 | 39 | 8 |
| 0.35T | 14 | 16 | 6 | 109 | 17 | 23 | 57 | 11 | |
| 0.65T | 17 | 17.5 | 8 | 131 | 20 | 27 | 59 | 12 | |
| 1T | 20 | 20.5 | 10 | 153 | 27 | 33 | 72 | 14.5 | |
| 1.5T | 24 | 27 | 12 | 185 | 32 | 37.5 | 83 | 17 |
